| Features |
| 8 on-board zones (16 w/ zone doubling) |
| Built-in access control features |
| Supports PCS Series, IP Module (IP150) and Voice Module (VDMP3) |
| In-field firmware upgrade via 307USB, Babyware and WinLoad |
| Selectable input resistors for EOL and Tamper |
| Compatible with NEware V4.0 or higher |
| Automatic Daylight Savings Time feature |
| PGM1 can be used as a 2-wire smoke input |
| Program remote controls using the master or installer codes |
| Built-in real-time clock backup battery |
| 1.7A switching power supply |
| 1 supervised bell output, auxiliary output and telephone line |
| Patented 2 opto coupler dialer circuit - the most reliable dialer in the industry (US Patents 5751803, RE39406) |
| Push button software reset (reset to default values and restart) |
| Push button to activate or deactivate the Auxiliary output |
| Fits in a 28cm x 28cm x 7.6cm (11in x 11in x 3in) metal box |
| The EVO series share the same programming for easy panel substitution |
| EN 50131 grade 3 |
|
 |
| |
